Minitower ExeGate BAA-303M

Specification

Cases Features
Model	BAA-303M
Case Type	MiniTower
Motherboard Support	mATX
Chassis Material	Steel
Material Thickness, mm	0,4
Material of front and side panels	Plastic / Steel
Material of front panel	Plastic
Material of left panel	Steel
Material of right panel	Steel
Number of screws for mounting the side panel, pcs	4
Hinge For The Lock	Yes
Case Color	Black
Chassis Color	Black
Power
PSU Type	ATX
Power supply location	At the top of the rear side
PSU models	w/o PSU
PSU models	AAA350, AAA400, AAA450, AA500, UNS350, UNS400, UNS450, UNS500
Recommended ExeGate PSU	Series AAA, Series AA, Series Special UNS
Construction
Internal 3,5" Drive Bay	1 (Instead of 120mm fan)
Internal 2,5" Drive Bay	2 (1 instead of 1x3.5")
Expansion Slots	4
Cooling System
Places for installation on the front panel	1 x 12 cm
Places for installation on the rear panel	1 x 8/9 cm
Places to install on the side panel	1 x 12 cm
Recommended ExeGate fans	8 cm, 9 cm, 12 cm
Interfaces
Interface location	At the top of the front panel
USB 2.0 Type-A	2
Audio I/O Ports	HD Audio 2 x 3.5mm
Other parameters
Max. motherboard length, mm	244
Max. height of the CPU fan, mm	140
Max. PSU length, mm	180
Max. SVGA length, mm	240
Chassis dimensions
Width, mm	168
Height, mm	350
Depth, mm	255
Case Dimensions
Width, mm	170
Height, mm	350
Depth, mm	268
Carton Dimensions
Width, mm	205
Height, mm	310
Depth, mm	385
Net Weight , kg	1,4
Gross Weight , kg	1,9
